FEATURES:
- A high-precision wet tile saw which uses continuous rim diamond blades only
- The unique water circulation design minimizes water loss and spillage while the water tray is easy to mount and refill.
- The dimensionally stable table allows accurate cutting and the parallel cutting guide with the angle guide plate allow precise guidance of the workpiece.
- The sturdy motor mount system allows the motor to tilt up to 45 degrees for accurate miter cuts.
- The AC induction motor operates at a very stable speed, is quiet, water-resistant and long-lasting.
SPECIFICATIONS:
| Model |
TS9 |
|---|
| Motor Type |
Single Phase AC Induction |
|---|
| Power Output |
800W |
|---|
| Voltage |
110-120V~ 50-60Hz, 220-240V~ 50-60Hz |
|---|
| No Load/Min-1 |
3000 (50Hz), 3600 (60Hz) |
|---|
| Max. Blade Diameter |
230mm (9") |
|---|
| Blade Bore |
25.4mm (1") |
|---|
| Bevel Capability |
0-45 deg. |
|---|
| Max. Cutting Depth-Straight |
48mm (1-7/8") |
|---|
| Max. Cutting Depth- At 45 Deg. |
37mm (1-7/16") |
|---|
| Table Cutting Width -Left |
305mm (12") |
|---|
| Table Cutting Width -Right |
147mm (5-3/4") |
|---|
| Protection |
IP44 |
|---|
| Dimensions(LxWxH) |
660mm x 595mm x 320mm |
|---|
| Net Weight |
14.7kg (32.41 Lbs) |
|---|
Standard Accessories: Diamond Blade, Parallel Cutting Guide, Angle Guide Plate,
M8 Combination Wrench, m19 Combination Wrench
